It is suitable for cleaning the welding corner joints of plastic doors andwindows, controlled by two-axis numerical control system, and easy to operate.

It can store processing programs of various profiles, and the secondprocessing can be started with one key.It can complete the cleaning of the outer elevation and the upper andlower plane welds of various profiles.It can realize size error compensation with high precision.

Numerical control system, solenoid valve, triplet and other majorcomponents are all famous brand products, with reliable performanceand long service life.

It can realize arc differential compensation and diagonal differentialcompensation, and can ideally meet the needs of making high-qualitydoors and windows with various sectional profiles.

Detailed parameters

NOITEMCSYH01-1800
1Input power supply380V/50Hz
2Input power1.4kW
3Milling cutter rotary speed2800r/min
4Working air pressure0.5~0.8MPa
5Height of processed profile30~120mm
6Width of processed profile20~120mm
7Overall dimension2000x1820x1500mm
8WeightAbout 700kg
